Temporary Prefab Steel Structure Warehouse Building For Site Management

  • 1
  • 2
  • 3

Downpipe Diameter : Φ110 PVC rainspout pipes

Supply Ability : 20000-30000 ㎡

Main Structure : H-Beam, Q355B Section Steel

Ventilator Size : Φ500mm 304SS unpowered ventilator

Payment Terms : L/C,T/T

High-Strength Bolts : Grade 10.9 intensive bolts

Brand Name : YAGO Industry

Model Number : YGKL16

Roof Purlin : Q235B, C Section Steel, Galvanized 275g

Wall Purlin : Q235B, C Section Steel, Galvanized 275g

Packaging Details : By Pallet or As Request

Place of Origin : CHINA

Delivery Time : 24-45Days

Certification : ISO;CE

MOQ : 150㎡

Contact Now

High-Quality Prefab Steel Structure Building for Site Management
The High-Quality Prefab Steel Structure Building is an elite administrative solution engineered for long-term site management in heavy industrial and infrastructure sectors. Unlike lightweight modular cabins, this building utilizes a professional-grade Q355B H-Beam skeleton assembled with Grade 10.9 high-torque bolts, offering the structural integrity of a permanent facility with the flexibility of a prefab. Designed to be a command center for engineers and project leads, it integrates an advanced 304 stainless steel ventilation system and a reinforced bracing network to provide a secure, climate-stable, and professional workspace in any terrain.
Product Advantages
  • Superior Material Specification: Features Q355B low-alloy steel, providing significantly higher yield strength and durability compared to standard carbon steel buildings.
  • Precision Industrial Assembly: Utilizes Grade 10.9 high-strength intensive bolts for primary connections, ensuring a rigid, vibration-resistant framework that maintains its geometric alignment over years of use.
  • Multi-Axial Stability System: Incorporates a systematic bracing architecture—including Knee Bracing, Cross Bracing, and Column Bracing—to offer exceptional resistance against seismic activity and gale-force wind loads.
  • Passive Air Quality Management: Equipped with Φ 500mm 304SS unpowered ventilators that leverage natural airflow to exhaust heat and stale air, maintaining a fresh indoor environment without added energy costs.
  • Industrial-Grade Water Shedding: Features high-capacity Stainless Steel gutters and Φ110 PVC downpipes, engineered to handle extreme precipitation and prevent perimeter soil erosion or water ingress.
Application Scenarios
  • Regional Project Headquarters: A centralized administrative hub for managing large-scale highway, railway, or bridge infrastructure projects.
  • Mining Operational Command Centers: High-durability office space for managing day-to-day extraction, safety, and logistics in rugged mineral zones.
  • On-Site Engineering & Design Studios: A stable, climate-controlled environment for technical teams to review blueprints and conduct geological data analysis.
  • Energy Sector Administrative Hubs: Professional site management offices for oil refineries, solar farms, or wind turbine installation projects.
  • Governmental Site Coordination Bases: High-quality temporary facilities for urban renewal or disaster reconstruction management teams.
Frequently Asked Questions
Q1: What is the benefit of using Q355B H-Beams for a site management office?
A: Q355B steel offers superior load-bearing capacity and impact resistance compared to standard Q235 steel. For site management hubs, this means a safer, more permanent-feeling structure that can support larger clear spans and heavier roof loads without internal pillars.
Q2: How does the "Grade 10.9 Bolt" connection impact the building's quality?
A: Grade 10.9 intensive bolts are high-strength fasteners used in heavy machinery and bridge construction. They provide much higher clamping force than standard bolts, ensuring that the management building remains completely stable and silent even in high-vibration environments.
Q3: Can this building maintain a comfortable temperature in hot climates?
A: Yes. Beyond the insulated sandwich panels, we include Φ 500mm 304SS unpowered ventilators. These units continuously draw out hot air from the ceiling cavity, significantly reducing the load on your HVAC system and maintaining better indoor air quality for your staff.
Q4: Why does the structural plan include so many types of bracing?
A: Stability is critical for high-quality prefabs. The combination of cross, knee, and column bracing creates a rigid 3D framework. This multi-axial support prevents the "sway" often found in cheaper prefab buildings, ensuring the safety of your administrative team and equipment.
Q5: Is the drainage system built to handle heavy tropical rain?
A: Absolutely. We use Stainless Steel gutters which are more durable and have a higher flow capacity than standard plastic or thin-steel gutters. Paired with Φ 110 large-diameter downpipes, the system can rapidly clear heavy rainfall to protect the building's foundation.
Specifications
Main Steel Frame System
Component Specification
Main Structure H-Beam, Q355B section steel with paint as per client request
Roof Purlin Q235B, C Section steel, Galvanized 275g
Wall Purlin Q235B, C Section steel, Galvanized 275g
Intensive Bolt Grade 10.9 intensive bolts
Ordinary Bolt Galvanized bolts, grade 4.8
Anchor Bolt Q235B anchor bolts as per design
Bracing System
Component Specification
Cross Brace Φ20, steel Q235, With paint or Hot dip Galvanized as per client request
Knee Bracing L50*4, steel Q235, With paint or Hot dip Galvanized as per client request
Column Bracing Φ20, steel Q235, With paint or Hot dip Galvanized as per client request
Tie Bar Φ89*3, steel Q235, With paint or Hot dip Galvanized as per client request
Batter Brace Φ12 round steel bar, steel Q235, With paint or Hot dip Galvanized as per client request
Roofing System
Component Specification
Roof Panel Roof with Galvanized Color Steel Sheet Or Insulated Sandwich panel as per client request
Edge Cover Galvanized Color Steel Sheet
Fittings & Accessories Nails, Screws, Glue, Bolts etc.
Gutter Stainless Steel Gutter
Rainspout Pipes Φ110 PVC rainspout pipes
Unpowered Ventilator Φ500mm 304SS unpowered ventilator
Wall System
Component Specification
Exterior Wall Outside Panel Wall with Galvanized Color Steel Sheet Or Insulated Sandwich panel as per client request
Edge Cover Galvanized Color Steel Sheet
Fittings & Accessories Nails, Screws, Glue, Bolts etc.
